LUTRON HOMEWORKS QSX

SKU: LUTRON-HOMEWORKS-QSX

HomeWorks QSX is Lutron’s top-tier residential system, designed for whole-home light, shade, appliance and temperature control in residences up to 50,000 sq ft. The system is built from HQP7 processors, each carrying one or two configurable links that the integrator assigns either to a QS wired device link or to a Clear Connect Type A wireless link — so a single project can mix wired architectural keypads and dimming panels with retrofit wireless devices. Up to 16 processors and gateways can be joined into one system, giving a ceiling of 10,000 zones and 32 configurable links. Programming is done in Lutron Designer, and the same Ethernet connection carries third-party integration and processor-to-processor traffic.

• Up to 16 processors / gateways and 10,000 zones on one system
• Each HQP7 processor carries 1 or 2 configurable links, assignable to QS wired or Clear Connect Type A wireless
• QS wired link: 99 devices and 512 switch legs per link
• Clear Connect Type A link: 99 devices and 100 switch legs per link
• Ethernet for Lutron Designer, third-party integration and processor-to-processor communication
• Scales to residences of up to 50,000 sq ft

Datasheet includes full specifications — share it with your consultant or contractor.
