CONTROL SYSTEMS

From simple scene control to complex media facades — reliable control architecture for every project scale.

Effective facade control requires matching the right protocol and controller to project requirements. Simple installations may need only scheduled scene changes, while media facades demand sophisticated content management. We design control architectures that balance capability with usability.

CONTROL PROTOCOLS

DMX512

LEARN MORE →

Industry-standard protocol for reliable fixture control. 512 channels per universe, daisy-chain topology.

SPECIFICATIONS

512 channels/universe

44Hz refresh rate

400m max cable length

32 devices per run

BEST FOR

Standard facade installations

Color-changing systems

Show control

Art-Net

Ethernet-based protocol for large-scale installations. Multiple universes over standard network infrastructure.

SPECIFICATIONS

Up to 32,768 universes

Ethernet transport

Network redundancy

Remote monitoring

BEST FOR

Large facades

Multi-building installations

Media facades

sACN (E1.31)

Streaming ACN for high-performance network control. Native multicast support for efficient data distribution.

SPECIFICATIONS

63,999 universes max

Multicast capable

Priority system

Synchronization

BEST FOR

High-performance installations

Synchronized displays

Broadcast environments

Pixel SPI

High-speed serial protocol for individual pixel control. Direct driver communication for animations.

SPECIFICATIONS

Individual LED control

High refresh rates

Various chipsets (WS2812, APA102)

Short cable runs

BEST FOR

Pixel facades

Media displays

Animation sequences

CONTROLLER TYPES

Stand-alone Controllers

Self-contained units for simple installations. Astronomical clock, scenes, and schedules.

• Astronomical timer

• Scene storage

• Simple scheduling

• No network required

Media Servers

Advanced content management and playback. Real-time processing for complex animations.

• Video playback

• Real-time effects

• Content scheduling

• Multi-output

Building Integration

Connection to BMS and building automation. KNX gateway integration for coordinated control.

• BMS connectivity

• KNX integration

• Scheduler sync

• Energy reporting

Cloud/Remote

Web-based monitoring and control. Remote scene changes and diagnostics.

• Remote access

• Status monitoring

• Alert notifications

• Scene updates

PROGRAMMING WORKFLOW

Fixture Addressing

Assign unique addresses to each fixture or fixture group

Patching

Map fixtures to controller outputs in software

Scene Programming

Create static and dynamic lighting scenes

Scheduling

Set time-based triggers and astronomical events

Testing

Night-time commissioning and fine-tuning

Documentation

Complete as-built records and user training

CRITICAL CONSIDERATIONS

INFRASTRUCTURE

• Plan cable routes early in construction
• Include network infrastructure for Art-Net/sACN
• Ensure accessible equipment locations

RELIABILITY

• Build in redundancy for critical systems
• Specify surge protection
• Plan for remote monitoring and alerts
